The SERIES SGZ Gages have dual psi and bar (x100 kPa) scales with ±1.5% full-scale accuracy. The Series SGZ gages are designed with 304 SS housings and 316 SS wetted parts for excellent chemical compatibility. These gages cover a wide variety of ranges in either bottom or back connection configurations. Series SGZ gages employ an easy-open breather plug on top, which allows liquid filled units to breathe, relieving any built up internal pressures. Plug easily pops open and does not need to be entirely removed or cut like a typical gages' rubber plug grommet.

Features:
• Stainless steel housing and wetted parts to resist ambient corrosion for longer service life in harsh environments
• Higher accuracy gage for value-sensitive applications requiring more precise measurement and where vibration is a concern
• Optional sliding pointer clearly mark to make visible critical ranges and high and low points
• Liquid fillable gage with easy open breather plug provides smoother damped movement of pointer
• Back or bottom mounting and compact size provides for mounting with dimensional limitations

Approvals:

Applications:
• Vacuums in pneumatic conveying lines
• Positive pressure in compressed air headers
• Corrosive ambient environments

Specifications:

Service:	Compatible gases and liquids.
Wetted Materials:	316 L SS Tube, 316 SS connector.
Housing:	304 SS
Lens:	Polycarbonate.
Accuracy:	±1.5% FS.
Pressure Limit:	FS range.
Temperature Limits:	-4 to 140°F (-20 to 60°C).
Size:	2.5" (63 mm).
Process Connections:	1/4" male NPT.
Weight:	4.9 oz (141 g) bottom, 5.8 oz (164 g) back. Add 3.7 oz (104 g) for glycerin fill.
